Pet Ultrasound and Echocardiography

The ultrasound machine is one of the most widely used imaging tools in veterinary medicine, second only to radiographs (X-rays). It is commonly used to diagnose pregnancy in both people and animals, so that’s what most pet owners are familiar with, but we use the ultrasound machine for lots of other things as well. An ultrasound scan is safe and economical. Unlike with X-rays, no ionizing radiation is produced by the ultrasound machine.

An ultrasound machine transmits sound waves at a much higher frequency than we can hear with our ears. The sound waves reflect back in greater or lesser amounts depending on the density of the material they hit. The reflected sound waves that bounce back are picked up by a receiver. A computer analyzes the time delay and amplitude of the returning echo and forms an image on a screen. The depth of a structure producing an echo is determined by the amount of “round trip” time of the transmitted pulse of sound and the returning echo. Fluids and tissues reflect sound the best. Air, gas, and bones prevent the transmission of the sound wave.

Pulses of sound and the images produced are updated approximately 30 times a second, so an ultrasound allows our veterinarians to see an image of the heart contracting or a baby moving, just like viewing a movie that consists of thousands of individual images. A single image can be selected, stored and printed as a photograph, or the entire movie can be recorded on videotape or computer.

Ultrasound allows us to look at the insides of organs, such as the heart, liver or urinary bladder, without an incision. We can use it to look at muscles, tendons and ligaments so, for example, we could diagnose a torn biceps tendon in a dog’s shoulder or a tumor inside a painful, swollen muscle. An echocardiogram, in which the sound waves are reflected off the heart, is another type of ultrasound study.

With the ultrasound machine we can measure the ability of the heart to contract, gauge the thickness of the bladder or intestinal walls, detect bladder stones, gallstones or fluid pockets, such as in the uterus with pregnancy or a cyst in a kidney. Guided by the ultrasound image, a veterinary can direct a needle into a specific organ, tumor or a nodule and obtain a tissue or fluid sample for analysis. This allows us to obtain samples from the liver, spleen or other organs without the need for invasive surgery. Because needle biopsy samples are small they are not always diagnostic, but they are a safer alternative for some pets than more major biopsy procedures in which a larger sample can be obtained.

Most pets will need to be shaved for the ultrasound procedure – since air doesn’t transmit ultrasound waves, the air trapped in the fur deflects the wave and makes the ultrasound ineffective. The gel is applied between the pet and the transducer, which transmits the sound waves and detects them bouncing back again, to further block out air between it and the patient.

Depending on the pet and the procedure needed, performing the ultrasound exam may require sedation or anesthesia. It’s uncomfortable when the ultrasound probe is pushed up under the ribcage to look at the liver and kidneys. Some pets also find being restrained in one position for 15 minutes or more to be stressful or frightening. Small incisions may need to be made to obtain biopsy samples guided by the ultrasound machine, so anesthesia is almost always required for these. Procedures rarely requiring a sedative include scanning for pregnancy, ultrasound of the bladder or echocardiogram.

The ultrasound scan itself is very safe. Biopsies carry some risk of bleeding, perforation or the spread of an existing infection. Your veterinarian can discuss the risks for your particular pet before the procedure.

The cost of an ultrasound scan varies tremendously depending on how long it will take and what procedures are being done. The price of the scan will cover not only the veterinarian’s time but also the cost of this expensive equipment. In the past, we have referred our ultrasound cases to Lakeshore Veterinary Specialists or our mobile cardiologist. We don’t consider ourselves expert ultrasonographers so there are some things, especially echocardiograms, that we don’t feel we are competent to do. Many abdominal ultrasounds can be done here at our animal hospital though, for less cost than seeing a specialist.
